MMA-M18 Series

IGBT INVERTER ARC WELDER

Instruction:

● High frequency(40KHZ-100KHZ),improve the efficiency of the whole machine,save energy.

● Pretty appearance,light weight,stable.

● Have the advantage of easily start arc,stable current,perfect molding.

● Adopt all kinds of acidic,alkaline welding rod.

● High rated duty and have better function for push compensation.

● Use for altitude work,fieldwork,indoor fitment.

Contact us

  • Product Details
  • leave a message

  • MODEL MMA-315A-M18  MMA-400A-M18 MMA-500A-M18 MMA-315A-N-M18 MMA-400A-N-M18 MMA-500A-N-M18 MMA-630A-N-M18
    Rated input voltage(V) 3~380 3~380 3~380 3~380 3~380 3~380 3~380
    No-load voltage(V)  65 70 75 68 68 72 72
    Current range(A)  40-315 40-400 40-500 40-315 40-400 40-500 40-630
    Rated duty(%) 60% 60% 60% 60% 60% 60% 60%
    Input capacity(KVA)  12.8 18 25 12.8 18 25 34.7
    Class of insulation  F F F F F F F
    Weight(Kg)  18 19 21 19 20 22 24
    Dimension(cm) 1PC 51×25×39 60×32×48.5 64×34×50 60×32×48.5 64×34×50 64×34×50 64×34×50
