BX1-C1/C3 Series-Shenyuan Electro-machinery Incorporated Corporation

BX1-C1/C3 Series

AC.ARC WELDER

Instruction:

● Single-phase,fan-cooled stick electrod welding machines for MMA-welding in alternating current(AC)stepless regulation of welding current.

● With hermostatic protection.Use the normal welding rod.

● Electrode holder,earth clamp,welding cable.

● Brush/hammer,protective mask,carton box.

Contact us

Product Details
leave a message

MODEL	BX1-130A -C1	BX1-160A -C1	BX1-180A -C1	BX1-200A -C1	BX1-250A -C1	BX1-130A -C3	BX1-160A -C3	BX1-180A -C3	BX1-200A -C3	BX1-250A -C3
Rated input voltage(V)	220/380	220/380	220/380	220/380	220/380	220/380	220/380	220/380	220/380	220/380
Rated input voltage(V)	110/220	110/220	110/220	110/220	110/220	110/220	110/220	110/220	110/220	110/220
No-load voltage(V)	48	48	48	48	48	48	48	48	48	48
Current range(A)	50-130	70-160	80-180	80-200	90-250	50-130	70-160	80-180	80-200	90-250
Rated duty(%)	10%	10%	10%	10%	10%	10%	10%	10%	10%	10%
Input capacity(KVA)	5.2	6.4	7.8	8.4	9.6	5.2	6.4	7.8	8.4	9.6
Class of insulation	H	H	H	H	H	H	H	H	H	H
Applied welding rod(mm)	2-3.2	2-3.2	2-4	2-4	2-5	2-3.2	2-3.2	2-4	2-4	2-5
Weight(Kg)	16.5	19	20	21	21.5	16.5	19	20	21	21.5
Dimension(cm) 1PC	47×26.5×31.5	47×26.5×31.5	47×26.5×31.5	47×26.5×31.5	47×26.5×31.5	47×26.5×31.5	47×26.5×31.5	47×26.5×31.5	47×26.5×31.5	47×26.5×31.5
