MMA-17 Series

IGBT INVERTER ARC WELDER

Instruction:

● High frequency(40KHZ-100KHZ),improve the efficiency of the whole machine,save energy.

● Pretty appearance,light weight,stable.

● Have the advantage of easily start arc,stable current,perfect molding.

● Adopt all kinds of acidic,alkaline welding rod.

● High rated duty and have better function for push compensation.

● Use for altitude work,fieldwork,indoor fitment.

Contact us

  • Product Details
  • leave a message

  • MODEL MMA-160A-17  MMA-180A-17 MMA-200A-17 MMA-250A-17 MMA-300A-17  MMA-350A-17 MMA-400A-17
    Rated input voltage(V) 1~230 1~230 1~230 1~230 1~230 1~230 1~230
    Rated input voltage(V) 1~110 1~110 1~110 1~110 1~110 1~110 1~110
    No-load voltage(V)  56 56 56 60 65 65 65
    Current range(A)  30-160 30-180 30-200 30-250 40-300 40-350 40-400
    Rated duty(%) 60% 60% 60% 60% 60% 60% 60%
    Input capacity(KVA)  5.3 6.1 7.0 9.4 12 15 18
    Class of insulation  F F F F F F F
    Weight(Kg)  4.5 5 5.5 6 6.5 15 18
    Dimension(cm) 1PC 40×23×28 40×23×28 40×23×28 43.5×24×30 43.5×24×30 51×25×39 51×25×39
    Dimension(cm) 4PCS 82.5×48.5×30  82.5×48.5×30 82.5×48.5×30 89.5×50.5×32 89.5×50.5×32 / /
