BX6-C/B Series

AC.ARC WELDER

Instruction:

● Tap type transformer,step current adjustment fan cooling,high efficiency and safety.

● Compactness light,portable suitable for home and small factory.

● We have two kinds of transformer one is aluminium,the other is coper.

Contact us

  • Product Details
  • leave a message

  • MODEL BX6-160A-C BX6-200A-C BX6-250A-C BX6-300A-C BX6-160A-B BX6-200A-B BX6-250A-B BX6-300A-B
    Rated input voltage(V) 220/380 220/380 220/380 220/380 220/380 220/380 220/380 220/380
    Rated input voltage(V) 110/220 110/220 110/220 110/220 110/220 110/220 110/220 110/220
    No-load voltage(V)  48 48 48 48 48 48 48 48
    Current range(A)  60-160 70-200 80-250 90-300 60-160 70-200 80-250 90-300
    Rated Duty Cycle(%) 20 20 20 20 20 20 20 20
    Input capacity(KVA)  9.1 12.5 15.9 22.8 9.1 12.5 15.9 22.8
    Class of insulation  F F F F F F F F
    Applied welding rod(mm) 2-3.2 2-3.2 2.5-4 2.5-6 2-3.2 2-3.2 2.5-4 2.5-6
    Weight(Kg)  20.5 23.5 25 28 20.5 23.5 25 28
    Packing Dimension(cm) 47×21.5×32.5 47×21.5×32.5 47×21.5×32.5 50×24.5×35.5 47×21.5×32.5 47×21.5×32.5 47×21.5×32.5 50×24.5×35.5
