BX7 Series

AC.ARC WELDER

Instruction:

● Single-phase,fan-cooled stick electrod welding machines for MMA-welding in alternating current(AC)stepless regulation of welding current.

● With hermostatic protection.Use the normal welding rod.

● Electrode holder,earth clamp,welding cable.

● Brush/hammer,protective mask,carton box.

Contact us

  • Product Details
  • leave a message

  • MODEL BX7-160A BX7-180A BX7-200A BX7-250A
    Rated input voltage(V) 230 230 230 230
    Rated input voltage(V) 110 110 110 110
    No-load voltage(V)  48 48 48 48
    Current range(A)  0-160 0-180 0-200 0-250
    Rated duty(%) 20 20 20 20
    Input capacity(KVA)  6 8 8 10
    Class of insulation  H H H H
    Usable electrodes(mm) 2-3.2 2-4 2-4 2-5
    Weight(Kg)  17 18 20 21
    Dimension(cm) 1PC 47×22×31.5 47×22×31.5 47×22×31.5 47×22×31.5
