Home / Product / Welding Machine / Others / MIG/MMA-Y3/Y5 Series

MIG/MMA-Y3/Y5 Series

INVERTER CO2 GAS PROTECTION WELDINGMACHINE(INTEGRATED)

Instruction:

● Apply high frequency inverter technology,feature optimized design,light effect and energy saving.

● With automatic arc lenght compensating function,stable electric arc, less splashing, electric archas high penetration force.

● Deep bath, beautiful appearance.

● With excellent dynamic response.

● Continuously and persistently weld workpiece,high efficiency with high current.

Contact us

  • Product Details
  • leave a message

  • MODEL MIG/MMA-250A
    -Y3     		 MIG/MMA-270A
    -Y3     		 MIG/MMA-280A
    -Y5    		 MIG/MMA-350A
    -Y5    		 MIG/MMA-350N
    -Y5    		 MIG/MMA-400N
    -Y5
    Rated input voltage(V) 1~230 1~230 3~380 3~380 3~380 3~380
    No-load voltage(V)  56 65 65 65 65 65
    Current range(A)  40-250 40-270 40-280 40-350 40-350 50-400
    Rated duty(%) 60% 60% 60% 60% 60% 60%
    Input capacity(KVA)  8.3 9.3 9.8 13.8 13.8 17
    Class of insulation  F F F F F F
    Appied welding rod(mm) 0.6-1.0 0.8-1.2 0.8-1.2 0.8-1.6 0.8-1.6 0.8-1.6
    Weight(Kg)  22 24 29 31 38 42
    Dimension(cm) 1PC 62×30×56 62×30×56 65×33×58 65×33×58 65×33×58 65×33×58
