CUT-M19 Series

IGBT INVERTER PLASMA CUTTER

Instruction:

● Portable,fan-cooled,thermostatic protectio,starting arc with contact.

● Adopt with advanced IGBT inverter technology,lightweight,accord with EMC standard

● Stepless current adjustment,suit for PLASMA CUTTING.

● Perfect with overheating,over load,over current,over/lack voltage protection.

● With complete accessories CUT torch,earth clamp,carton box.

Contact us

  • Product Details
  • leave a message

  • MODEL CUT-40A-M19 CUT-50A-M19 CUT-60A-M19 CUT-80A-M19 CUT-100A-N-M19 CUT-120A-N-M19
    Rated input voltage(V) 1~230 1~230 1~230 3~380 3~380 3~380
    No-load voltage(V)  240 240 255 270 310 310
    Current range(A)  15-40 15-50 30-60 30-80 30-100 30-120
    Rated duty(%) 60% 60% 60% 60% 60% 60%
    Input capacity(KVA)  4.8 6.3 7.8 11.2 18 19.2
    Class of insulation  F F F F F F
    Weight(Kg)  10 12 18 29 36 37
    Dimension(cm) 1PC 50.5×24×30 50.5×24×30  54×25×39  64×34×50  64×34×50 64×34×50
