MMA-M19 WIDE VOLTAGE Series

IGBT INVERTER ARC WELDER

Instruction:

● High frequency(40KHZ-100KHZ),improve the efficiency of the whole machine,save energy.

● Pretty appearance,light weight,stable.

● Have the advantage of easily start arc,stable current,perfect molding.

● Adopt all kinds of acidic,alkaline welding rod.

● High rated duty and have better function for push compensation.

● Use for altitude work,fieldwork,indoor fitment.

● 150V-260V,wide voltage input.

● 160V-460V,wide voltage input.

● Suit for generator

● Welding cable can extend to 25m

Contact us

  • Product Details
  • leave a message

  • MODEL MMA-220A-K-M19 MMA-260A-K-M19  MMA-280A-K-M19 MMA-300A-K-M19 MMA-250A-K-M19 MMA-315A-K-M19 MMA-400A-K-M19
    Rated input voltage(V) 1~220(150-260) 1~220(150-260) 1~220(150-260) 1~220(150-260) 1~220/380(160-460) 1~220/380(160-460) 1~220/380(160-460)
    No-load voltage(V)  70 70 70 70 85 85 85
    Current range(A)  30-220 30-260 30-280 40-300 40-250 40-315 40-400
    Rated duty(%) 60% 60% 60% 60% 60% 60% 60%
    Input capacity(KVA)  7.9 9.9 10.9 12 9.4 12.8 18
    Class of insulation  F F F F F F F
    Weight(Kg)  5 5.5 6 6.5 15 16 19
    Dimension(cm) 1PC 37×21×26 40×23×28 43.5×24×30 43.5×24×30 51×25×39 51×25×39 60×30×48.5
    Dimension(cm) 4PCS 76.5×44.5×28 82.5×48.5×30 89.5×50.5×32 89.5×50.5×32 / / /
