CUT-M20 Series TIG/MMA-M20 Series

IGBT INVERTER TIG/MMA WELDER

Instruction:

● Single-phase,portable,fan-cooled,thermostatic protectio,starting arc with contact.

● Adopt with advanced IGBT inverter technology,lightweight,accord with EMC standard

● Stepless current adjustment,suit for TIG/MMA welding.

● Perfect with overheating,over load,over current,over/lack voltage protection.

● With complete accessories:TIG series TIG torch,earth clamp,brush/hammer,protective

● mask carton box,TIG/MMA series TIG torch,electrode holder,earth clamp,brush/hammer,

● protective mask,carton box

● Single-phase,portable,fan-cooled,thermostatic protectio,starting arc with contact.

● Adopt with advanced IGBT inverter technology,lightweight,accord with EMC standard

● Stepless current adjustment,suit for PLASMA CUTTING.

● Perfect with overheating,over load,over current,over/lack voltage protection.

● With complete accessories CUT torch,earth clamp,carton box.

Contact us

  • Product Details
  • leave a message

  • MODEL TIG/MMA-180A-M20 TIG/MMA-200A-M20 TIG/MMA-250A-M20 CUT-40A-M20  CUT-50A-M20  CUT-60A-M20
    Rated input voltage(V) 1~230 1~230 1~230 1~230 1~230 1~230
    Rated input voltage(V) 1~110 1~110 1~110 / / /
    No-load voltage(V)  56 56 56 240 240 255
    Current range(A)  10-180 10-200 10-250 15-40 15-50 30-60
    Rated duty(%) 60% 60% 60% 60% 60% 60%
    Input capacity(KVA)  3.9 4.5 6.3 4.8 6.3 7.8
    Class of insulation  F F F F F F
    Weight(Kg)  6.8 7 7.2 10 12 18
    Dimension(cm) 1PC 47.5×24×30 47.5×24×30  47.5×24×30  50.5×24×30  50.5×24×30 54×25×39
