MMA-M20 Series

IGBT INVERTER ARC WELDER

Instruction:

● High frequency(40KHZ-100KHZ),improve the efficiency of the whole machine,save energy.

● Pretty appearance,light weight,stable.

● Have the advantage of easily start arc,stable current,perfect molding.

● Adopt all kinds of acidic,alkaline welding rod.

● High rated duty and have better function for push compensation.

● Use for altitude work,fieldwork,indoor fitment.

Contact us

  • Product Details
  • leave a message

  • MODEL MMA-300A-M20 MMA-350A-M20 MMA-400A-M20 MMA-315A-M20
    Rated input voltage(V) 1~230 1~230 1~230 3~380
    Rated input voltage(V) 1~110 1~110 1~110 /
    No-load voltage(V)  65 65 65 65
    Current range(A)  40-300 40-350 40-400 40-315
    Rated duty(%) 60% 60% 60% 60%
    Input capacity(KVA)  12 15 18 12.5
    Class of insulation  F F F F
    Weight(Kg)  15 18 19 18
    Dimension(cm) 1PC 51×25×39  51×25×39  51×25×39  51×25×39
