Home / Product / Welding Machine / M20 series / MIG/MMA-M20(5kg) Series

MIG/MMA-M20(5kg) Series

INVERTER CO2 GAS PROTECTION WELDINGMACHINE(INTEGRATED)

Instruction:

● Apply high frequency inverter technology,feature optimized design,light effect and energy saving.

● With automatic arc lenght compensating function,stable electric arc, less splashing, electric archas high penetration force.

● Deep bath, beautiful appearance.

● With excellent dynamic response.

● Continuously and persistently weld workpiece,high efficiency with high current.

Contact us

  • Product Details
  • leave a message

  • MODEL MIG/MMA-160A-M20(5kg) MIG/MMA-180A-M20(5kg) MIG/MMA-200A-M20(5kg) MIG/MMA-250A-M20(5kg)
    Rated input voltage(V) 1~230 1~230 1~230 1~230
    Rated input voltage(V) 1~110 1~110 1~110 1~110
    No-load voltage(V)  56 56 56 60
    Current range(A)  40-160 40-180 40-200 40-250
    Rated duty(%) 60% 60% 60% 60%
    Input capacity(KVA)  4.4 5.2 6 8.3
    Class of insulation  F F F F
    Applied welding rod(mm) 0.6-0.8 0.6-0.8 0.6-1.0 0.6-1.0
    Weight(Kg)  11 11 11.5 13
    Dimension(cm) 1PC 60×27×37 60×27×37 60×27×37  60×27×37
