MIG/MMA-Y-20(1kg) Series

INVERTER CO2 GAS PROTECTION WELDINGMACHINE(INTEGRATED)

Instruction:

● Apply high frequency inverter technology,feature optimized design,light effect and energy saving.

● With automatic arc lenght compensating function,stable electric arc, less splashing, electric archas high penetration force.

● Deep bath, beautiful appearance.

● With excellent dynamic response.

● Continuously and persistently weld workpiece,high efficiency with high current.

Contact us

  • Product Details
  • leave a message

  • MODEL MIG-130A
    -Y-20(1kg)    		 MIG-150A
    -Y-20(1kg)    		 MIG-180A
    -Y-20(1kg)    		 MIG/MMA-130A
    -Y-20(1kg)    		 MIG/MMA-150A
    -Y-20(1kg)    		 MIG/MMA-180A
    -Y-20(1kg)
    Rated input voltage(V) 1~230 1~230 1~230 1~230 1~230 1~230
    No-load voltage(V)  56 56 56 56 56 56
    Current range(A)  40-130 40-150 40-180 40-130 40-150 40-180
    Rated duty(%) 60% 60% 60% 60% 60% 60%
    Input capacity(KVA)  3.3 4 5.2 3.3 4 5.2
    Class of insulation  F F F F F F
    Applied welding rod(mm) 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8
    Weight(Kg)  6.8 7 7.2 6.8 7 7.2
    Dimension(cm) 1PC 47.5×24×30 47.5×24×30 47.5×24×30  47.5×24×30 47.5×24×30 47.5×24×30
